ASUS ROG Strix X870-A Gaming WiFi, AMD ATX motherboard, 16+2+2 power stages, DDR5 slots, four M.2 slots, PCIe 5.0 with full support for next-gen GPUs, WiFi 7, USB 20Gbps w/ PD 3.0 up to 30W

ASUS ROG Strix X870-A Gaming WiFi, AMD ATX motherboard, 16+2+2 power stages, DDR5 slots, four M.2 slots, PCIe 5.0 with full support for next-gen GPUs, WiFi 7, USB 20Gbps w/ PD 3.0 up to 30W

Brand: ASUS

Processor manufacturer
AMD
Processor socket
Socket AM5
Supported processor sockets
Socket AM5

About this item

  • AMD Socket AM5
  • PC ATX AMD X870 Realtek ALC4080 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 192 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 6
  • BIOS type: UEFI AMI 256 Mbit Clear CMOS button
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4

£324.39 (inc. VAT)

Free delivery on trade orders. Returns accepted within 30 days. Delivery & returns info › Trade account & bulk pricing ›

Product description

ASUS ROG STRIX X870-A GAMING WIFI, AMD, Socket AM5, Socket AM5, DDR5-SDRAM, 192 GB, DIMM

Product information

Processor
Processor manufacturerAMD
Processor socketSocket AM5
Supported processor socketsSocket AM5
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & Non-ECC
Maximum internal memory192 GB
Unbuffered memoryYes
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Number of HDDs supported2
Number of storage drives supported6
RAID supportYes
RAID levels0, 1, 10, 5
Graphics
Parallel processing technology supportNot supported
On-board graphics cardNo
Internal I/O
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
USB 3.2 Gen 2x2 connectors1
Number of SATA III connectors2
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
Number of chassis fan connectors5
Chassis intrusion connectorYes
12V power connectorYes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB4 Gen 2x2 ports quantity2
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity1
Headphone outputs1
Microphone inYes
S/PDIF out portYes
WiFi-AP antenna jack1
Network
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standardsWi-Fi 7 (802.11be)
BluetoothYes
Bluetooth version5.4
Features
Motherboard chipsetAMD X870
Audio chipRealtek ALC4080
Audio output channels7.1 channels
Product colourAluminium
Component forPC
Motherboard form factorATX
Motherboard chipset familyAMD
Windows operating systems supportedWindows 11
Expansion slots
PCI Express x16 (Gen 4.x) slots2
PCI Express x16 (Gen 5.x) slots1
Number of M.2 (M) slots4
BIOS
BIOS typeUEFI AMI
BIOS memory size256 Mbit
Clear CMOS buttonYes
Packaging data
Package width353 mm
Package depth273 mm
Package height68 mm
Package weight2.32 kg
Weight & dimensions
Width305 mm
Depth244 mm
Height50 mm
Packaging content
Cables includedSATA
Other features
Weight1.84 kg

Documents, compatibility & warranty

Safety, standards & compliance

Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standardsWi-Fi 7 (802.11be)

Compatibility & requirements

Supported storage drive interfacesM.2, SATA III
Ethernet LANYes
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiYes
BluetoothYes
Bluetooth version5.4
Windows operating systems supportedWindows 11
